YOULI New Style Pneumatic Manual Welding Sterile Aseptic Sampling Valve
Subscribe free newsletter to get latest information.
Model NO.:D001003002004D-01
Pur Qty. / Ref FOB Price
1 PieceUS $136.45-142.75 / Piece
Product Details:Ckeck View
Min. Order:1 Piece
Port:Ningbo, China
Production Capacity:5000sets/Month
Payment Terms:L/C, T/T, D/P, Western Union, Paypal, Money Gram
Material Quality:304, 304L, 316L (1.4301, 1.4307, 1.4404)
Connection Ends:Threaded Triclamp, Welded
Size:1/2", 3/4"
Gasket:EPDM, Silicone, PTFE in Accordance with FDA 17
Max. Pressure:10bar 145psi
Temperature:20degree Celsius~135degree Celsius
HS Code:8481804090
Trademark:YOULI
Specification:ISO, 3A, SGS
Transport Package:Shrink Wrap-Carton Case-Exporting Plywood Case
Origin:Wenzhou City, China
Model NO.D001003002004D-01
PressureMedium Pressure
PowerPneumatic
Temperature of MediaNomal Temperature
MediaWater, Juice, Milk, Beer, Pharmaceutical
HS Code8481804090
TrademarkYOULI
SpecificationISO, 3A, SGS
Transport PackageShrink Wrap-Carton Case-Exporting Plywood Case
OriginWenzhou City, China
Products Name:YOULI New Style Pneumatic Manual Welding Sterile Aseptic Sampling Valve
Pneumatic Sampling Valve
Aseptic Sampling Valve
Body material
|
SUS304,SUS316(CF8M),SUS 304L(CF8),SUS 316L(CF3M),1.4301/304,316L/1.4404,etc.
|
Full port
|
1/4"-1/2"(DN8-DN15)
|
Working pressure
|
PN16,1.6Mpa,16Bar
|
Working temperature
|
- 20 ℃ ~ + 140°C,Optional(- 20℃ ~ + 250°C)
|
Welding connection
|
DlN 11850-2 with 11850-1/SMS/3A/IS0 Series etc
|
Connection type
|
Weld,Thread,Socket,Clamped,Flanged,Wafer,KF
|
Ring type
|
The types of sealing rings include O-ring, E-ring, U-ring, V-ring, Y-ring, rectangular ring, etc
|
Production process
|
Investment casting, CNC lathe, Test, Cleaning, Packing, Storage
|
Capacity to produce
|
10000PCS/Mouth
|
Certification
|
CE, ISO, our factory has been inspected by leyon and TUV
|
MOQ
|
1PC
|
HS Code
|
7307220000
|
Trademark
|
YOULI
|
Application
|
Suitable for water, oil, air and some corrosive liquid etc
|
Buyer's drawings or designs are available
|
|
Package
|
Cartons without pallet
|
Cartons with pallet
|
|
Or as buyer's requirements
|
|
Delivery details
|
According to the quantities and specifications of each order
|
Normal delivery time is from 10 to 15 days after receiving the deposit
|
Operating Principle
Its mainly applied to extract sample from tank or pipeline. It also can be assembled at the bottom of the tank or pipeline to drain away the remains.It is apply for the food, chemical, pharmaceutical, cosmetics and biotechnology industries. As well as all other sectors requiring sanitary type equipment.
Applications
It is widely applied to many fileds, such as beer, beverage, dairy food, fruit juice, pharmacy, biological etc.
Company Profile Wenzhou YouLi Machinery Co., Ltd. is a modern enterprise that integrates design, manufacturing, sales, and services. The main products include ball valves,butterfly valves, gate valves, globe valves, filters, pressure reducing valves, safety valves,exhaust valves, angle seat valves, control valves, water control valves, knife gate valves, solenoid valves, discharge valves,steam traps,balance valves,breather valves, diaphragm valves, vacuum valves, needle valves, flame arresters,pumps, pipe fttings,sight glasses,manholes, pneumatic and electric accessories,fluorine-lined valves, and sanitary valves and fttings.
Our Service
On Samples | Buyer bear the air fee, but this fee will be reduced from order directly |
On After Sales | Free replacement if there is any quality problem |
On Delivery | Never delay delivery time |
On Materials | Ensure material pure |
Ensure material pure | Welcome to order our products |
FAQ
Q: May I have free samples before ordering?
Yes, our company is very pleased to send you free samples for quality test as long as freight cost being paid by buyers themselves.
Q: What’s the MOQ?
The majority of products are fully in stock, so we accept 1 piece as the minimum order quantity.
Q: Does your company have the export license?
Yes, we have more than 4 years export experience, we can do FOB, C&F, CIF, DDU and DDP (Russian Only).
Q: What’s the payment term?
For small testing orders, we accept Paypal, Western Union, T/T and Credit Card.
For mass orders, we accept T/T and L/C.
Q: How would you minimize damages during delivery?
Standard: mass orders will be packed by many carbon boxes and filled in plywood cases.
Available requirement: blister packing for every piece of product, plastic caps for clamp connected products.
Q: How would you choose the shipment way?
Basically, we will select shipment ways based on four factors (order quantity, delivery time, costs and customs policy), then listcouples of reasonable options with Pros and Cons to customers, letting them to decide.
NO. | Name | File Detail | Size | Down |
---|
video
gif
YOULI New Style Pneumatic Manual Welding Sterile Aseptic Sampling Valve
Model NO.:D001003002004D-01
NO. | Mat | Spec | Wgt(kg) | Ps |
---|---|---|---|---|
1 | 316L | DN8-K25.4MM | ||
2 | 316L | DN8-K50.5MM |
YOULI New Style Pneumatic Manual Welding Sterile Aseptic Sampling Valve
Model NO.:D001003002004D-01
NO. | Mat | Spec | SPrice($) | CPrice(RMB) | Wgt(kg) | Ps1.1 |
---|---|---|---|---|---|---|
1 | 316L | DN8-K25.4MM | $142.75 | 680 | ||
2 | 316L | DN8-K50.5MM | $136.45 | 650 |
YOULI New Style Pneumatic Manual Welding Sterile Aseptic Sampling Valve
Model NO.:D001003002004D-01
NO. | Mat | Spec | SPrice($) | Wgt(kg) | Ps |
---|---|---|---|---|---|
1 | 316L | DN8-K25.4MM | $142.75 | ||
2 | 316L | DN8-K50.5MM | $136.45 |
